Imaging
Image Sensor
1"-Type MOS
Effective Sensor Resolution
15.03 Megapixel
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Video Only
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/10000 to 1 Second
Shutter Angle
3 to 360°
ISO/Gain Sensitivity
Native: 400 to 12,800
Gain: -3 to 36 dB
Signal-to-Noise Ratio
Not Specified by Manufacturer
Precise Scan Rate Control
Yes
White Balance
Presets: ATW, Set A, Set B
Range: 2000 to 15,000K
Lens
Focal Length
8.8 to 176mm (35mm Equivalent: 24.5 to 490mm)
Zoom
20x Optical
Maximum Aperture
f/2.8 to 4.5
Minimum Focus Distance
Not Specified by Manufacturer
Filter Size
67 mm
Control Rings
Focus
Zoom
Iris
Focus
Focus Mode
Automatic, Manual Focus
Video Capture
Internal Recording
H.264/MOV 4:2:2 10-Bit
3840 x 2160 from 1 to 30.00 fps (150 to 200 Mb/s VBR)
1920 x 1080p from 1 to 60.00 fps (50 to 200 Mb/s VBR)
1920 x 1080p at 120 fps (100 to 400 Mb/s)
1920 x 1080i at 50/59.94 fps
*Sensor Crops During Recording
H.265 Long GOP/MOV 4:2:0 10-Bit
3840 x 2160 from 1 to 60.00 fps (100 to 200 Mb/s VBR)
Video Output
4:2:2 10-Bit via HDMI
3840 x 2160 at 23.98/25/29.97/50/59.94 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
4:2:2 10-Bit via SDI/BNC
1920 x 1080p at 50/59.94 fps
1920 x 1080i at 50/59.94 fps
1920 x 1080PsF at 23.98/25/29.97 fps
1280 x 720 at 50/59.94 fps
Broadcast Output
NTSC with 2000 TV Lines
Fast-/Slow-Motion Support
Yes
Interval Recording Modes
No
Gamma Curve
HDR-HLG, Panasonic V-Log
Built-In Microphone
Stereo
Audio Recording
MOV: 4-Channel, 24-Bit at 48 kHz via LPCM Audio
AVCHD: 2-Channel, 16-Bit at 48 kHz
MXF: 4-Channel, 24-Bit at 48 kHz via AAC LC Audio
MXF: 4-Channel, 16-Bit at 48 kHz
IP Streaming
H.264, RTMP, RTMPS, RTP, RTSP, SRT
3840 x 2160 at 24p, 25p, 30p, 50p, 60p (0.5 to 75.00 Mb/s)
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Internal Storage
No
Video I/O
1x BNC (12G-SDI) Output
1x HDMI 2.0 Output
1x 1/8" / 3.5 mm TRRS A/V (Composite) Output
1x RJ45 (NDI) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Line Input on Camera Body
1x XLR 3-Pin Mic/Line Input on Included Handle (+48 V Phantom Power)
1x XLR 3-Pin Mic/Line Input on Camera Body (+48 V Phantom Power)
Power I/O
1x Barrel (12VDC) Input
Other I/O
1x BNC (Timecode) Input/Output
1x BNC (Genlock) Input
1x 2.5 mm Sub-Mini (Remote)
1x RJ45 (Ethernet, LAN) (Shared with Video Output)
1x USB-C (USB 3.2 / 3.1 Gen 1)
1x USB-A (USB 2.0) Host
Wireless
No
Mobile App Compatible
Yes: Android & iOS
App Name: CX ROP
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Primary Monitor: Articulating 3.2" Touchscreen LCD
Resolution
No
Viewfinder
Type
Electronic (OLED)
Resolution
1,770,000 Dot
Power
Battery
Panasonic AG-VBR Series
Power Consumption
≤26 W
Environmental
Operating Conditions
32 to 104°F / 0 to 40°C at 10 to 80% Humidity
