Canon super 35 mm CMOS sensor
- The EOS C100 is equipped with the advanced 16:9 super 35 mm Canon CMOS sensor. The large sensor format opens up cinematic vistas and permits a shallow depth-of-field for arresting images. The 8.3-megapixel sensor and its fine pixel pitch permit greater sensitivity in low light while minimizing noise. The EOS C100 captures red, green, and blue channels independently for Full HD 1920 x 1080 video. The resulting picture features the color and image quality of a three-chip camera with a single sensor. The optimized pixel count allows the camera to avoid additive processing as a result of skipping lines during capture; sensor sensitivity is maintained and aliasing or other degradation of the image is prevented.
Canon DIGIC DV III Image Processor
- Designed and built by Canon for the highest quality HD RGB processing, the DIGIC DV III Image Processor uses proprietary circuits and architecture to deliver exceptional image quality at the highest speeds, with low power consumption and minimal heat output. It processes the RGB image data - originating from the single CMOS sensor of the camera - into three channels to maintain the rich resolution and clean color fidelity formerly possible only in three-chip sensor designs.
Exceptional low light sensitivity and wide dynamic range
- The EOS C100 incorporates the first Canon CMOS sensor designed specifically for high frame rate motion pictures, offering not only high resolution and shallow depth-of-field but also high sensitivity with low noise. Working together, Canon's super 35 mm sensor and DIGIC DV III Image Processor achieve a remarkably high signal-to-noise ratio that enables recordings with great detail and dynamic range even in minimal light. Users will appreciate the camera's 12 stops of dynamic range at all ISO speed settings from 320 to 20000.
Canon Log Gamma and wide Dr Gamma
- Canon Log Gamma preserves shadow and highlight detail for maximum editing and grading in post-production without degrading image quality; contrast and sharpness are subdued with characteristics similar to negative film. Canon Log Gamma emphasizes rich gradients from mid-range to highlights and realizes 12-stops of Dynamic Range (DR). At ISO850, Canon Log Gamma enables 5.3 stops of latitude above optimal exposure, broadening the available dynamic range in color grading.
Multiple recording modes and frame rates
- The EOS C100 supports shooting AVCHD bit rates up to 24 Mbps (LPCM) at a maximum resolution of Full HD, 1920 x 1080. The EOS C100 supports relay recording of long takes between dual SD cards or can write video to both cards for redundancy in the event of SD card failure. Pre REC mode buffers approximately 3 seconds before the tally light activates, instilling confidence that you have captured your take as you planned it.
Full manual control and focusing aids
- The EOS C100 offers complete manual control of each aspect of the recording process. Create and recall custom picture settings, camera functions, and display options. Built-in ND filters expand control over exposure, depth-of-field, and motion capture. Manual control of video and audio capture gives you the power to fully control what you capture.
Specifications
General
- Product Type: Camcorder - 1080p
- Lens Included: Body only
- Camcorder Sensor Resolution: 9.84 Mpix
- Effective Video Resolution: 8.29 Mpix
- Widescreen Video Capture: Yes
- Camcorder Media Type: Flash card
- Optical Sensor Type: CMOS
- Optical Sensor Size: 13.8 x 24.6 mm
- Field of View Crop Factor: 1.53
- Image Processor: DIGIC DV III
- Digital Video Format: AVCHD
- Image Recording Format: JPEG
- Sensitivity: F10
- Signal to Noise Ratio (typical): 54 dB
- Audio Signal Format: Dolby Digital AC-3 (2 channel), Linear PCM
- Features: SMPTE Color Bars, selectable frame rates, zebra pattern, waveform monitor
- AV Interfaces: Composite video/audio, HDMI
Exposure & White Balance
- Light Sensitivity: ISO 320-20000
- Min Illumination: 0.25 lux
- Exposure Modes: Manual
- White Balance: Custom, automatic, presets
- White Balance Presets: Tungsten light, daylight, 2000K - 15000K (100K steps)
- Max Shutter Speed: 1/2000 sec
- Min Shutter Speed: 1/3 sec
- Exposure Compensation: ±2 EV range, in 1/4 EV steps
- Gain Selection: +12 dB, +18 dB, +3 dB, +6 dB, 0 dB, -3 dB, + 9 dB, +15 dB, +30 dB, +24 dB, +21 dB, -6 dB
- Built-in ND Filters: 1/4, 1/64, 1/16
Lens System
- Lens System Mounting: Canon EF
Additional Features
- Low Lux / Night Mode: Yes
- Additional Features: USB 2.0 compatibility, display brightness control, sharpness control, display contrast control, saturation control, Dolby Digital AC-3 (2 channel) recording, takes photos while movie recording, Pre-Rec function, Relay Recording, HD-to-SD downconversion, 24p Cinema Mode, 25p Cinema Mode, peripheral illumination correction, display color control, Bayer mosaic RGB filter, Noise Reduction control, Canon Log Gamma mode, Dual Pixel CMOS AF technology
Viewfinder
- Viewfinder Type: Electronic
- Viewfinder Color Support: Color
- Viewfinder Diagonal Size: 0.24"
- Viewfinder Resolution: 1,555,000 pixels
- Field Coverage: 100%
- Dioptric Correction Range: -5.5 to +2
- Image Aspect Ratio: 16:9
Display
- Type: 3.5" LCD display
- Resolution: 922,000 pixels
- Display Features: Rotating
Microphone
- Microphone Operation Mode: Stereo
- Microphone Features: Sensitivity control
Connections
- Connector Type: 1 x Hi-Speed USB 1 x HDMI output 1 x composite video/audio output ( mini-phone 3.5 mm 4-pole ) 1 x balanced audio input ( XLR x 2 ) 1 x microphone ( mini-phone stereo 3.5 mm ) 1 x headphones ( mini-phone stereo 3.5 mm ) 1 x Control-L (LANC)
- Memory Card Slot: Dual SD card
Software
- Software: Drivers & Utilities
Miscellaneous
- Included Accessories: Battery charger, body cap, shoulder strap, AC power adapter, eyecup, camera grip, camcorder handle, tripod adapter base, thumb rest
Battery
- Battery Type: Canon BP-955
- Details: 1 x Canon BP-955 Li-ion rechargeable battery ( included ) 1 x Canon BP-975 Li-ion rechargeable battery ( optional )
Memory / Storage
- Memory Card Slot: Dual SD card
- Supported Memory Cards: SD Memory Card, SDXC Memory Card, SDHC Memory Card
- Image Storage: JPEG 1920 x 1080
- Video Capture: AVCHD - 1920 x 1080 - 24Mbps AVCHD - 1920 x 1080 - 17Mbps AVCHD - 1440 x 1080 - 7Mbps
Dimensions & Weight
- Width: 5.3 in
- Depth: 5.1 in
- Height: 6.7 in
- Weight: 2.2 lbs
Environmental Parameters
- Min Operating Temperature: 32 °F
- Max Operating Temperature: 113 °F
- Humidity Range Operating: 0 - 85%
Universal Product Identifiers
- Brand: Canon
- GTIN: 00013803147926
