Key Specs
Lens Mount
Canon RF
Effective Sensor Resolution
24.2 Megapixel (6000 x 4000)
Image Sensor
APS-C
Image Stabilization
Digital
ISO Sensitivity
Native: 100 to 32,000 (100 to 51,200 Extended)
Max Recording Modes
H.264/H.265/MPEG-4
Up to UHD 4K at 23.98/25/29.97 fps
Max Video Output
Up to UHD 4K
Memory Card Slot
Single Slot: SD/SDHC/SDXC
Video I/O
1x Micro-HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C Data Output (Shared with Power Input)
Wireless
Wi-Fi 4 (802.11n) / Bluetooth 4.2
Display Type
Articulating 3" Touchscreen LCD
Battery
1x LP-E17 Rechargeable (Included)
Imaging
Lens Mount
Canon RF
Sensor Resolution
Effective: 24.2 Megapixel (6000 x 4000)
Actual: 25.5 Megapixel
Image Sensor
22.3 x 14.9 mm (APS-C) CMOS
Sensor Crop (35mm Equivalent)
Crop Factor: 1.6x
*Additional Crop Occurs in Select Video Modes
Image Stabilization
Digital (Video Only)
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
Electronic Shutter
1/8000 to 30 Seconds
Electronic Front Curtain Shutter
1/4000 to 30 Seconds
Bulb/Time Mode
Bulb & Time Mode
ISO Sensitivity
Native: 100 to 32,000 (100 to 51,200 Extended)
Metering Method
Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes
Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation
-3 to +3 EV (1/3 EV Steps)
Metering Range
-2 to 20 EV
White Balance
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Continuous Shooting
Up to 15 fps at Maximum Resolution for up to 7 Frames (Raw) / 28 Frames (JPEG)
Interval Recording
Yes
Self-Timer
2/10-Second Delay
Still Image Capture
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Image File Format
C-RAW, HEIF, JPEG, Raw
Video Capture
Internal Recording
H.264/H.265/MPEG-4
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120 fps
Video Output
3840 x 2160
1920 x 1080
Fast-/Slow-Motion Support
Slow-Motion Only
Recording Limit
1-Hour Maximum
IP Streaming
No
Built-In Microphone
Stereo
Interface
Memory Card Slot
Single Slot: SD/SDHC/SDXC
Internal Storage
No
Video I/O
1x Micro-HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C Data Output (Shared with Power Input)
Wireless
Wi-Fi 4 (802.11n) / Bluetooth 4.2
Mobile App Compatible
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
GPS
*Via Connected Smartphone
Monitor
Display Type
Articulating 3" Touchscreen LCD
Resolution
1,620,000 Dot
Viewfinder
Type
Electronic (OLED)
Size
0.39"
Resolution
2,360,000 Dot
Eye Point
22 mm
Coverage
100%
Magnification
Approx. 0.96x
Diopter Adjustment
-3 to +1
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points
Phase Detection: 4503
Video
Phase Detection: 3713
Autofocus Sensitivity
-4 to +20 EV
Flash
Built-In Flash/Light
Yes, Flash Only
Flash Modes
Auto, Manual, Red-Eye Reduction, Slow Sync
Guide Number
19.7' / 6 m at ISO 100
Maximum Sync Speed
1/250 Second
Flash Compensation
-3 to +3 EV (1/3 EV Steps)
Dedicated Flash System
eTTL
Shoe Mount
1x Hot Shoe
Non-Shoe Flash Connection
No
