Imaging
Lens Mount Canon RF
Camera Format Full-Frame (1x Crop Factor)
Pixels Actual: 47.1 Megapixel
Effective: 45.0 Megapixel
Maximum Resolution 8192 x 5464
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Sensor Type CMOS
Sensor Size 36 x 24 mm
Image File Format JPEG, Raw
Bit Depth 14-Bit
Image Stabilization Sensor-Shift, 5-Axis
Exposure Control
ISO Sensitivity Auto, 100 to 51200 (Extended: 100 to 102400)
Shutter Speed Mechanical Shutter
1/8000 to 30 Seconds
Electronic Front Curtain Shutter
1/8000 to 30 Seconds
Electronic Shutter
1/8000 to 0.5 Seconds
Metering Method Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Metering Range -3 to 20 EV
White Balance Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Continuous Shooting Mechanical Shutter
Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG)
Electronic Shutter
Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG)
Interval Recording Yes
Self-Timer 2/10-Second Delay
Video
Recording Modes Raw 12-Bit
DCI 8K (8192 x 4320) at 23.976p/24.00p/25p/29.97p [2600 Mb/s]
H.265 4:2:2 10-Bit
DCI 8K (8192 x 4320) at 23.976p/24.00p/25p/29.97p [680 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.976p/25p/29.97p [680 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/59.94p/100p/119.88p [170 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p/100p/119.88p [170 to 1880 Mb/s]
Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p [28 to 230 Mb/s]
H.264 4:2:0 8-Bit
DCI 8K (8192 x 4320) at 23.976p/24.00p/25p/29.97p [470 to 1300 Mb/s]
UHD 8K (7680 x 4320) at 23.976p/25p/29.97p [470 to 1300 Mb/s]
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p/100p/119.88p [120 to 1880 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p/100p/119.88p [120 to 1880 Mb/s]
Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p [12 to 180 Mb/s]
External Recording Modes 4:2:2 10-Bit
DCI 4K (4096 x 2160) up to 59.94p
UHD 4K (3840 x 2160) up to 59.94p
Recording Limit Up to 29 Minutes, 59 Seconds
Video Encoding NTSC/PAL
Audio Recording Built-In Microphone (Stereo)
External Microphone Input
Audio File Format AAC, Linear PCM
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S)
Autofocus Points Phase Detection: 1053
Autofocus Sensitivity -6 to +20 EV
Viewfinder and Monitor
Viewfinder Type Electronic (OLED)
Viewfinder Size 0.5"
Viewfinder Resolution 5,760,000 Dot
Viewfinder Eye Point 23 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 0.76x
Diopter Adjustment -4 to +2
Monitor Size 3.2"
Monitor Resolution 2,100,000 Dot
Monitor Type Free-Angle Tilting Touchscreen LCD
Flash
Built-In Flash No
Maximum Sync Speed 1/250 Second
Flash Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System eTTL
External Flash Connection Hot Shoe
Interface
Memory Card Slot Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II)
Connectivity USB Type-C (USB 3.1), HDMI D (Micro), 3.5mm Headphone, 3.5mm Microphone
Wireless Wi-Fi
Bluetooth
GPS No
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 0 to 85%
Physical
Battery 1 x LP-E6NH Rechargeable Lithium-Ion
Dimensions (W x H x D) 5.43 x 3.84 x 3.46" / 138 x 97.5 x 88 mm
Weight 1.62 lb / 738 g (Body with Battery and Memory)
Kit Lens
Focal Length 24 to 105mm
Maximum Aperture f/4
Minimum Aperture f/22
Angle of View 84° to 23° 20'
Maximum Magnification 0.24x
Minimum Focus Distance 1.48' / 45 cm
Optical Design 18 Elements in 14 Groups
Diaphragm Blades 9, Rounded
Focus Type Autofocus
Image Stabilization Yes
Filter Size 77 mm (Front)
Dimensions (ø x L) 3.68 x 4.22" / 93.5 x 107.3 mm
Weight 1.54 lb / 700 g
