Canon R8 Specs
Imaging
Lens Mount Canon RF
Sensor Resolution Effective: 24.2 Megapixel
Image Sensor 35.9 x 23.9 mm (Full-Frame) CMOS
Image Stabilization Sensor-Shift, 5-Axis (Video Only)
Built-In ND Filter None
Capture Type Stills & Video
Exposure Control
Shutter Type Electronic Shutter
Shutter Speed Electronic Shutter
1/16000 Up to 30 Seconds in Manual Mode
1/16000 Up to 30 Seconds in Time Mode
1/8000 Up to 30 Second
Electronic Front Curtain Shutter
1/4000 Up to 30 Seconds
Bulb/Time Mode Bulb Mode, Time Mode
ISO Sensitivity Photo/Video
100 to 102,400 (Extended: 50 to 204,800)
Metering Method Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Metering Range -3 to 20 EV
White Balance Presets: Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Kelvin, Shade, Tungsten
Continuous Shooting Electronic Shutter
Up to 40 fps for up to 120 Frames (JPEG) / 56 Frames (Raw)
Up to 6 fps for up to 1000 Frames (JPEG) / 1000 Frames (Raw)
Interval Recording Yes
Self-Timer 2/10-Second Delay
Still Image Capture
Aspect Ratio 3:2
Image File Format C-RAW, HEIF, JPEG, Raw
Bit Depth 14-Bit
Video Capture
Internal Recording Modes H.264/H.265/MP4 4:2:2 10-Bit
UHD 4K (3840 x 2160) up to 23.98/25/29.97/50/59.94 fps
1920 x 1080 up to 23.98/25/29.97/50/59.94/100/120/150/180 fps
External Recording Modes None
Fast-/Slow-Motion Support Yes
Gamma Curve Canon Log 3, HDR-PQ
Recording Limit Up to 120 Minutes in 4K
Up to 120 Minutes in 1080p HFR
Broadcast Output NTSC/PAL
IP Streaming Yes
Built-In Microphone Type Stereo
Interface
Media/Memory Card Slot Single Slot: SD/SDHC/SDXC
Video I/O 1 x Micro-HDMI Output
Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body
1 x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output on Camera Body
Other I/O 1 x USB-C (USB 3.2 / 3.1 Gen 2)
Wireless 2.4 / 5 GHz Wi-Fi
Bluetooth 4.2 Control
Mobile App Compatible Yes
*As of February, 2023: Check with manufacturer for the most up-to-date compatibility
Global Positioning (GPS, GLONASS, etc.) None
Monitor
Size 3"
Resolution 1,620,000 Dot
Display Type Articulating Touchscreen LCD
Viewfinder
Type Built-In Electronic (OLED)
Size 0.39"
Resolution 2,360,000 Dot
Eye Point 22 mm
Coverage 100%
Magnification Approx. 70x
Diopter Adjustment -4 to +1
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points Photo
Phase Detection: 4897
Video
Phase Detection: 4067
Autofocus Sensitivity -6.5 to +21 EV
Flash
Built-In Flash No
Flash Modes Auto
Maximum Sync Speed 1/200 Second
Flash Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System eTTL
External Flash Connection Intelligent Hot Shoe
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 0 to 85%
