Imaging
Effective Sensor Resolution
Effective: 22.3 Megapixel (5760 x 3840)
Actual: 23.9 Megapixel
Image Sensor
18.4 x 12.3 mm (1.4"-Type) CMOS
Image Stabilization
Optical in Integrated Lens
Digital (Video Only)
Lens
Focal Length
8.2 to 25.6mm (35mm Equivalent: 16 to 50mm)
Optical Zoom
3.1x
Aperture
Maximum: f/2.8 to 4.5
Minimum: f/11
Focus Range
2" to Infinity / 5 cm to Infinity (Wide)
5.9" to Infinity / 15 cm to Infinity (Telephoto)
Optical Design
9 Elements in 8 Groups
Exposure Control
Shutter Speed
Electronic Shutter
1/16000 to 30 Seconds
Mechanical Shutter
1/2000 to 30 Seconds
Bulb/Time Mode
Bulb Mode
ISO/Gain Sensitivity
Native: 100 to 32,000 (100 to 51,200 Extended)
Video
Native: 100 to 12,800 (100 to 25,600 Extended)
Metering Method
Center-Weighted Average, Evaluative, Partial
Exposure Modes
Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation
-3 to +3 EV (1/3 EV Steps)
White Balance
Presets: Auto, Cloudy, Color Temperature, Flash, Fluorescent (White), Incandescent, Manual, Shade, Sunlight
Continuous Shooting
Up to 30 fps at Maximum Resolution
Interval Recording
Yes
Self-Timer
2/10-Second Delay
Still Image Capture
Aspect Ratio
3:2
Image File Format
C-RAW, HEIF, JPEG, Raw
Bit Depth
14-Bit
Video Capture
Internal Recording
H.264/H.265/MP4
3840 x 2160 at 23.98/25/29.97/50/59.94 fps (60 to 340 Mb/s)
1920 x 1080 at 23.98/29.97/50/59.94/100/120 fps (12 to 180 Mb/s)
Video Output
No
Recording Limit
No
IP Streaming
No
Built-In Microphone
Stereo (Microphone Location: Top)
Interface
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC (UHS-II)
Internal Storage
No
Video I/O
1x Micro-HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C 2.0 (Data) Output (Shared with Power Input)
Wireless
Wi-Fi 4 (802.11n) / Bluetooth 4.2
Mobile App Compatible
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Articulating 3" Touchscreen LCD
Resolution
1,040,000 Dot
Viewfinder
Type
No Viewfinder Support
Flash
Built-In Flash/Light
No
Shoe Mount
1x Intelligent Hot Shoe
Non-Shoe Flash Connection
No
