Canon XA35 3.09 MP Camcorder - 1080p

SKU #: CNXA35 | Manufacturer Part #: 1003C002
  • Brand New Factory Fresh
    Ships Within 1-2 Business Days
  • Click Here To See Our Return Policy.
Extended warranty available

Free Shipping!

Availability: In stock

Condition: New

List Price

$2,299.00

You Save

$400.00 (17%)

Price:

$1,899.00

Add to Cart

Canon XA35 3.09 MP Camcorder - 1080p Combining a compact form factor, professional video features, and an HD-SDI output, the Canon XA35 is well-suited for "run-and-gun" ENG productions, event coverage, corporate videos, and other applications that require a compact, broadcast-quality camera. It is equipped with a 20x Canon optical zoom lens with a versatile 35mm equivalent range of 26.8 to 576mm, and features a 1/2.84", HD CMOS Pro sensor with enhanced sensitivity for improved low-light performance over the previous model. To fit into your workflow, the camcorders captures up to 1920x1080 video at 23.98p, 29.97p, 59.94p, and 59.94i frame rates, while also offering Slow and Fast Motion recording modes, as well as an interval recording option to capture fast motion of up to 1200x the original speed.



In addition to the standard gamma recording mode, the XA35 offers Wide DR and Highlight Priority Gamma modes. Wide DR compresses high brightness areas to achieve a wider dynamic range of 600%. This not only helps suppress overexposure, but also produces smooth gradations in highlights and shadows, all while maintaining a finalized look that eliminates the need for post-production processing. The Highlight Priority Mode gives an HDR-like quality to your video by reducing the amount of highlight and mid-tone compression on the gamma curve, which helps to maintain highlight exposure. The mode also enhances brightness and saturation for more faithful color reproduction. A View Assist Mode is available to support this mode, enabling you to more accurately monitor what the final images will look like.



The XA35 features both a 3.5" OLED Touch Panel view screen with a 10,000:1 contrast ratio, and a color electronic viewfinder with 1,560,000 dots of resolution. The camera features full manual control and auto modes for exposure, focus, white balance, gain, and shutter speed. The camera provides professional features such as a pre-record buffer, peaking, zebra bars, color bars, and reference tone. The zoom speed is adjustable with variable, constant (with 16 different speed levels), fast, normal and slow settings. The camera features a detachable top handle with zoom toggle, record start/stop, IR emitter, tally light, accessory shoe, external mic holder and two XLR connectors with phantom power and manual audio level controls. The XA35 includes a built-in headphone jack and a mini-HDMI connector, and outputs composite video and audio via a 3.5mm four pole mini jack. For connecting with professional video equipment, the XA35 also features a SD/HD-SDI output for direct connection to news truck, an SDI switcher, or other professional video equipment. It also enables external recording of uncompressed video signals.



General

Product TypeCamcorder - 1080p
Camcorder Sensor Resolution3.09 MP
Effective Video Resolution2.91 MP
Widescreen Video CaptureYes
Camcorder Media TypeFlash card
Optical Sensor TypeHD CMOS Pro
Optical Sensor Size1/2.84"
Wireless InterfaceIEEE 802.11a/b/g/n
Optical Zoom20 x
Digital Zoom400 x
Image ProcessorDIGIC DV 4
Image StabilizerOptical (Dynamic SuperRange)
Face DetectionYes
Surround SoundDolby Digital AC-3 (2 channel) recording
SensorsDigital level meter
FeaturesSMPTE Color Bars, SMPTE Time Code, zebra pattern
Auto FocusTTL contrast and phase detection
AE/AF ControlSubject-tracking AF, Touch Area AF
Face DetectionFace-priority AF function
Digital Video FormatAVCHD, H.264
Image Recording FormatJPEG
Max Video Resolution1920 x 1080
Audio Signal FormatDolby Digital AC-3 (2 channel), Linear PCM
Auto Focus FeaturesFocus Peaking function, Manual Focus Check Live View
Interfaces ProvidedComposite video/audio, HDMI, HD-SDI, USB 2.0

Communications

Wireless InterfaceIEEE 802.11a/b/g/n
Connectivity FeaturesRemote control via mobile devices, remote live view

Exposure & White Balance

Min Illumination0.1 lux
Exposure MeteringMulti-segment, center-weighted
Exposure ModesProgram, automatic, manual, aperture-priority, shutter-priority
Capturing ProgramsSpotlight, portrait mode, night mode, fireworks, low light, sports mode, sunset, beach, snow
White BalanceCustom, automatic, presets
White Balance PresetsFluorescent, cloudy, tungsten light, daylight, shade, 2000K - 15000K (100K steps), fluorescent light (white)
Max Shutter Speed1/2000 sec
Min Shutter Speed1/6 sec
Exposure Compensation±3 EV range, in 1/2 EV steps
Gain SelectionAutomatic, 0 to +24 dB in 1 dB

Lens System

Type20 x zoom lens - 3.67 - 73.4 mm - f/1.8-2.8
Focal Length Equivalent to 35mm Camera26.8 - 576mm
Focus AdjustmentAutomatic, manual
Zoom AdjustmentMotorized drive
Lens Construction10 groups / 12 elements
Filter Size58 mm

Additional Features

Low Lux / Night ModeYes
Additional FeaturesQuickness control, GPS ready, brightness control, takes photos while movie recording, Wide Dynamic Range (WDR), Pre-Rec function, Relay Recording, HD-to-SD downconversion, digital tele-converter, 24p Cinema Mode, high-speed recording, Dual Stream Encoding, Smart AUTO, Bayer mosaic RGB filter, fast motion recording, Intelligent Image Stabilisation (IS), Audio Scene Select function, Backup recording, built-in FTP client function

Viewfinder

Viewfinder TypeElectronic - electronic
Viewfinder Color SupportColor
Viewfinder Diagonal Size0.24"
Viewfinder Resolution1,560,000 pixels
Optical Viewfinder Field Coverage100%
Optical Viewfinder Dioptric Correction Range-5.5 to +2
FeaturesTilting

Display

Type3.5" OLED display
Resolution1,230,000 pixels
Display Form FactorRotating (270°)
Touch ScreenYes
Display FeaturesColor control, contrast control, display brightness control, Touch AF

Microphone

Microphone Operation ModeStereo
Microphone FeaturesZoom, sensitivity control

Connections

Connector Type1 x headphones ( mini-phone stereo 3.5 mm ) 1 x microphone ( mini-phone 3.5 mm ) 2 x balanced audio input ( XLR ) 1 x USB 2.0 ( mini-USB Type B ) 1 x composite video/audio output ( mini-phone 3.5 mm 4-pole ) 1 x HDMI output ( 19 pin mini HDMI Type C ) 1 x remote control ( sub-mini phone stereo 2.5 mm ) 1 x timecode in 1 x HD/SD-SDI output
Memory Card SlotDual SD card

Miscellaneous

Included AccessoriesLens hood, AC power adapter, USB cable, HDMI cable, audio / video cable, camcorder handle, IR remote control

Battery

Battery TypeCanon BP-820
Details1 x Canon BP-820 Li-ion rechargeable battery ( included )
Battery Life DetailsVideo recording - 2.4 hours

Memory / Storage

Memory Card SlotDual SD card
Supported Memory CardsSD Memory Card, SDXC Memory Card, SDHC Memory Card
Video CaptureAVCHD - 1920 x 1080 - 60 fps - 28Mbps AVCHD - 1920 x 1080 - 60 fps - 24Mbps AVCHD - 1920 x 1080 - 60 fps - 17Mbps AVCHD - 1440 x 1080 - 60 fps - 5Mbps H.264 - 1920 x 1080 - 60 fps - 35Mbps H.264 - 1920 x 1080 - 30 fps - 24Mbps H.264 - 1920 x 1080 - 30 fps - 17Mbps H.264 - 1280 x 720 - 30 fps - 4Mbps H.264 - 640 x 360 - 30 fps - 3Mbps

Dimensions & Weight

Width4.3 in
Depth3.3 in
Height7.2 in
Weight26.98 oz

Environmental Parameters

Min Operating Temperature23 °F
Max Operating Temperature113 °F
Humidity Range Operating0 - 60%

Universal Product Identifiers

BrandCanon
Part Number1003C002
GTIN00013803267112
