| Effective Pixels |
3840 x 2160 pixels; Approx. 8.29 megapixels |
| Total Pixels |
4206 x 2340 pixels; Approx. 9.86 megapixels |
| Sensor Type |
CMOS |
| Sensor Size |
Super 35; 24.6 x 13.8 mm (28.2 mm diagonal); 6.4 ìm cell pitch |
| Scanning System |
Progressive |
| Number of Sensors |
1 |
| Filter |
RGB Primary Color Filter (Bayer Array) |
| Imaging Processor |
DiGic DV III |
| Interchangeable Lens System |
EF-mount for compatibility with EF, EF-S and EF Cinema lens systems |
| ND Filter |
Mechanical ND filter system with option of clear, 2, 4, and 6 stops) |
| Iris |
Manual setting in 1/2-step increments, 1/3-step increments or fine Push auto iris control |
| Peripheral Illumination Correction |
Available |
| Exposure Modes |
Manual; Push Auto Iris Control (metering system selection/AE shift possible) |
| Metering Modes |
Available (Standard Center Weighted, Spotlight, Backlight) |
| GAIN |
Normal Setting -6 dB to 30 dB / Fine Setting 0 dB to 24 dB in 0.5 dB increments |
| ISO |
3200 to 20,000 in 1/3 stop increments |
| Exposure Compensation / AE Shift |
Available |
| Sutter Modes |
3 Modes: OFF; Speed; Angle; Slow Shutter; Clear Scan Speed setting can be set in ½ or 1/3 stop increments |
| Shutter Speed Range |
59.94i/: 1/60 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8, 1/15, 1/30;
CS: 59.94 Hz - 250.27 Hz
PF30: 1/30 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8; CS: 29.97 Hz - 250.27 Hz
23.98p/PF24: 1/24 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12;
CS: 23.97 Hz - 250.27 Hz
50i: 1/50 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12 1/25;
CS: 50.00 Hz - 250.78 Hz
PF25: 1/25 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12;
CS: 25.00 Hz - 250.78 Hz |
| Shutter Angle Settings |
59.94i: 360, 240, 216, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25
PF30: 360, 240, 216, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25
23.98p/PF24: 360, 345.6, 288, 240, 180, 172.8, 144, 120, 90, 86.4, 72, 60, 45, 30, 22.5, 15, 11.25
50i: 360, 300, 240, 180, 150, 120, 90, 60, 45, 30, 22.50, 15, 11.25
PF25: 360, 300, 240, 180, 150, 120, 90, 60, 45, 30, 22.50, 15, 11.25 |
| Iris (Aperture) Range |
Lens Dependent |
| Focus Settings |
Manual; One-Shot AF |
| Autofocus System |
Available; AF is dependent on interchangeable lenses / TTL-Video Signal Sensing System |
| AF Metering Area |
Fixed at center of screen (4% of the screen) |
| AF Modes |
One-Shot AF |
| Signal System |
NTSC and PAL |
| Compression |
MPEG-4 AVC/H.264 |
| Color Space |
4:2:0 internal recording |
| Maximum Bit Rate |
24Mbps |
| Canon Log |
Available |
| Canon Wide Dynamic Range |
Available; Provides the same DR Range as Canon Log Gamma while maintaining a standard video curve |
| Recording Options |
24 Mbps LPCM - 1920 x 1080: 60i/PF30/PF24/24p/50i/25p
24 Mbps - 1920 x 1080: 60i/PF30/PF24/24p/50i/25p
17 Mbps - 1920 x 1080: 60i/PF30/PF24/24p/50i/25p
7 Mbps - 1440 x 1080: 60i/PF30/PF24/24p/50i/25p |
| Recording Format |
24 Mbps Mode: Linear PCM; 2-Channel; 16-Bit; 48 kHz All Other Modes: Dolby Digital AC3 |
| Built-in Microphone |
Stereo Microphone built in to Handle Unit |
| External Audio Inputs |
2 XLR inputs (Auto and Manual level settings)
External microphone terminal: (3.5 mm diameter) |
| XLR Mic Trimming |
Available; -12dB, -6 dB, 0dB, +6dB or +12 dB |
| Limiter |
Available |
| Built-in Speaker |
Yes; 16 level settings |
| Power Terminal |
Battery Pack: 7.4V / DC in: 8.4V |
| Battery |
BP-9 Series |
| Temperature and Humidity |
Performance requirements: 0ºC to 40ºC, 85% (relative humidity)
Operating requirements: -5ºC to 45ºC, 60% (relative humidity) |
| Language Support |
English, Japanese, Simplified Chinese, German, Spanish, French, Italian, Polish, Russian, Korean |
| Body Dimension WxHxD |
Approx. 5.3 x 6.7 x 5.1" / 135 x 170 x 129mm (with thumb rest) |
| Weight |
Approx. 2.25 lb / 1020g (body only) |
