Smooth surface and rounded corners make clean-up quick and easy
All purpose burners
All-purpose burner delivers two levels of BTU output to accommodate virtually all your cooking needs
Heavy Cast Square Grates
Porcelain upswept cooktop
Raised edges and porcelain-enameled surface makes cleaning incredibly easy
Lift-up cooktop
Cooktop lifts up to give you access to the subtop, where spills and crumbs can collect, to make cleaning effortless
Electronic pilotless ignition
Say farewell to the energy-wasting standing pilot! The electric pilotless ignition provides reliable operation.
APPEARANCE
Color Appearance
Stainless Steel
Control Knobs
Plastic
Handle
Stainless Steel Sculptured
CAPACITY
Total Capacity (cubic feet)
3.0
FEATURES
Configuration
Range with Warming Drawer
Ignition System
Electronic
Oven Cleaning Type
Standard Clean
Cooktop Burner Type
Standard
Cooktop Surface
Porcelain-EnamelLift-Up
All-Purpose Burners
(4) 9,100/8,000 BTU
Cooktop Burner Grate Material
Heavy Cast2 Doubles
Valves (Degree of Turn)
140
Broiler Drawer
Yes
Broiler Pan and Grid
Yes
Fuel Type
Natural Gas (factory set)
Leveling System
4 Leveling Legs
Oven Rack Features
2 Oven Racks4 Embossed Rack Positions
Porcelain-Enameled Subtop
Yes
Slide - Out Broiler Drawer
Yes
POWER / RATINGS
Oven/Broiler BTU Rating - LP (000's BTU's)
1300
Oven/Broiler BTU Rating - Nat. Gas (000's BTU's)
1300
Top Burner BTU Rating - LP (000's BTU's)
(4) 8.0
Top Burner BTU Rating - Nat. Gas (000's BTU's)
(4) 9.1
Volts/Hertz/Amps
120V; 60Hz; 5A
WARRANTY
Parts Warranty
Limited 1-year entire appliance
Labor Warranty
Limited 1-year entire appliance
WEIGHTS & DIMENSIONS
Approximate Shipping Weight
142.0
Cabinet Width
24.0
Net Weight (lbs.)
127.0
Oven Interior Dimensions (W x H x D) (in.)
20 x 15 x 16-1/4
Overall Depth
26.37
Overall Height
44.75
Height to Cooking Surface (in.)
36
Overall Width
24.0
