Key Specs
Sensor Resolution
Actual: 8.57 Megapixel
Effective: 8.29 Megapixel
Image Sensor
1/2.5"-Type MOS
Image Stabilization
Optical in Integrated Lens
ISO/Gain Sensitivity
Gain: 0 to 30 dB dB
Internal Recording
AVCHD 4:2:0 8-Bit
1920 x 1080p at 23.98/50/59.94 fps [21 to 25 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [17 to 21 Mb/s VBR]
1280 x 720 at 50/59.94 fps [8 Mb/s VBR]
H.264 ALL-Intra/MOV 4:2:2 8-Bit
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [100 to 200 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [100 Mb/s VBR]
H.264 Long GOP/MOV 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97 fps [150 Mb/s VBR]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps [50 to 100 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [50 to 100 Mb/s VBR]
H.264 Long GOP/MOV 4:2:0 8-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 150 Mb/s VBR]
H.264 Long GOP/MP4 4:2:0 8-Bit
3840 x 2160 at 23.98/25/29.97 fps [50 to 72 Mb/s VBR]
1920 x 1080p at 23.98/50/59.94 fps [50 Mb/s VBR]
H.265 Long GOP/MOV 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 200 Mb/s VBR]
H.265 Long GOP/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [72 to 100 Mb/s VBR]
Show More
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-I) [U3/V30 or Faster Recommended]
Video I/O
1x HDMI (Unspecified Signal) Output
Mobile App Compatible
Yes: Android & iOS
App Name: HC ROP
Functionality: Remote Control
Battery Type
Panasonic AG-VBR Series
Imaging
Sensor Resolution
Actual: 8.57 Megapixel
Effective: 8.29 Megapixel
Image Sensor
1/2.5"-Type MOS
Image Stabilization
Optical in Integrated Lens
Built-In ND Filter
Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/8000 to 1/6 Second
ISO/Gain Sensitivity
Gain: 0 to 30 dB dB
Minimum Illumination
1.5 Lux at 1/30 Shutter Speed
White Balance
Range: 2000 to 15,000K
Lens
Focal Length
4.1 to 98.9mm (35mm Equivalent: 25 to 600mm)
Optical Zoom Ratio
24x
Max Digital Zoom
48x
Maximum Aperture
f/1.8
Minimum Aperture
f/4
Minimum Focus Distance
3.94" / 10 cm (Wide) to 3.9' / 1.2 m (Tele)
Filter Size
62 mm
Control Rings
Focus
Zoom
Iris
Focus Control
Autofocus
Manual Focus
Video Capture
Internal Recording
AVCHD 4:2:0 8-Bit
1920 x 1080p at 23.98/50/59.94 fps [21 to 25 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [17 to 21 Mb/s VBR]
1280 x 720 at 50/59.94 fps [8 Mb/s VBR]
H.264 ALL-Intra/MOV 4:2:2 8-Bit
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [100 to 200 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [100 Mb/s VBR]
H.264 Long GOP/MOV 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97 fps [150 Mb/s VBR]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps [50 to 100 Mb/s VBR]
1920 x 1080i at 50/59.94 fps [50 to 100 Mb/s VBR]
H.264 Long GOP/MOV 4:2:0 8-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 150 Mb/s VBR]
H.264 Long GOP/MP4 4:2:0 8-Bit
3840 x 2160 at 23.98/25/29.97 fps [50 to 72 Mb/s VBR]
1920 x 1080p at 23.98/50/59.94 fps [50 Mb/s VBR]
H.265 Long GOP/MOV 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 200 Mb/s VBR]
H.265 Long GOP/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [72 to 100 Mb/s VBR]
Fast-/Slow-Motion Support
Yes
Built-In Microphone
Stereo
Audio Recording
MOV: 2-Channel 24-Bit LPCM Audio
MP4: 2-Channel 24-Bit AAC Audio
AVCHD: 2-Channel 24-Bit AC-3 Audio
IP Streaming
RTMP, RTP, RTSP
320 x 180 to 1920 x 1080 at 25p, 30p, 50p, 60p (0.5 to 24.00 Mb/s)
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-I) [U3/V30 or Faster Recommended]
Video I/O
1x HDMI (Unspecified Signal) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x Barrel (12VDC) Input
Other I/O
1x Micro-USB Input
1x 2.5 mm Sub-Mini Output
Wireless
2.4 GHz Wi-Fi 4 (802.11n)
Mobile App Compatible
Yes: Android & iOS
App Name: HC ROP
Functionality: Remote Control
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD
Resolution
Primary Monitor: 2,760,000 Dot
Viewfinder
Type
Electronic (LCD)
Resolution
1,560,000 Dot
Focus
Focus Mode
Automatic, Manual Focus
Power
Battery Type
Panasonic AG-VBR Series
Power Consumption
7.9 W
Environmental
Operating Conditions
32 to 104°F / 0 to 40°C at 10 to 80% Humidity
General
Shoe Mount
1x Intelligent Hot Shoe
Tripod Mounting Thread
1/4"-20 Female
Built-In Video Light
No
Dimensions (W x H x D)
10.1 x 5.1 x 3.7" / 257 x 129 x 93 mm (Without Handle)
Weight
2.65 lb / 1.2 kg (Body Only)
