Imaging
Image Sensor
1/2.5"-Type MOS
Effective Sensor Resolution
8.29 Megapixel
Image Stabilization
Digital
Built-In ND Filter
Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/8000 to 1/6 Second in Movie Mode
Sensitivity
f/1.8 at 4 lux
Minimum Illumination
1.5 Lux
White Balance
Range: 2000 to 15,000K
Presets: ATW, Auto
Lens
Focal Length
4.12 to 98.9mm (35mm Equivalent: 25 to 600mm)
Zoom
24x Optical
Maximum Aperture
f/1.8
Minimum Aperture
f/4
Filter Size
62 mm
Control Rings
Focus
Zoom
Focus
Focus Mode
Automatic, Manual Focus
Video Capture
Internal Recording
MOV 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
MOV 4:2:0 8/10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps
MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps
MP4 4:2:0 8-Bit
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080p at 23.98/50/59.94 fps
AVCHD 4:2:0 8-Bit
1920 x 1080p at 50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
Video Output
4:2:2 10-Bit via HDMI
3840 x 2160 at 23.98/25/29.97/50/59.94 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
720 x 576p at 50 fps
720 x 480p at 59.94 fps
4:2:2 10-Bit via SDI/BNC
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1920 x 1080PsF at 29.97 fps
1280 x 720 at 50/59.94 fps
720 x 576p at 59.94 fps
720 x 480p at 59.94 fps
Fast-/Slow-Motion Support
Yes
Built-In Microphone
Stereo
Audio Recording
AVCHD, MP4: 2-Channel, 16-Bit at 48 kHz
IP Streaming
H.264, RTMP, RTMPS, RTP, RTSP
1920 x 1080
1280 x 720
640 x 360
320 x 180
Interface
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC (UHS-I) [512 GB Maximum]
Internal Storage
No
Video I/O
1x HDMI Output
1x BNC (3G-SDI) Output
Audio I/O
2x XLR 3-Pin Mic/Line Input (+48 V Phantom Power)
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x USB-C (9VDC at 3 A) Input
Other I/O
1x 2.5 mm Sub-Mini (Remote) Control
1x USB-C
Wireless
2.4 GHz Radio/RF / 5.8 GHz Radio/RF
Mobile App Compatible
Yes: Android & iOS
App Name: HC ROP
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD
Viewfinder
Type
Electronic (OLED)
Resolution
1,770,000 Dot
Power
Battery
Panasonic AG-VBR Series
Power Consumption
12.3 W
