Imaging
Lens Mount
Micro Four Thirds
Sensor Resolution
Actual: 26.52 Megapixel
Effective: 25.2 Megapixel (5776 x 4336)
Image Sensor
17.3 x 13 mm (Four Thirds) BSI CMOS
Sensor Crop (35mm Equivalent)
Crop Factor: 2x
*Additional Crop Occurs in Select Video Modes
Image Stabilization
Sensor-Shift, 5-Axis
Built-In ND Filter
No
Capture Type
Stills & Video
Exposure Control
Shutter Type
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
Shutter Speed
Electronic Shutter
1/32000 to 60 Seconds
Electronic Front Curtain Shutter
1/2000 to 60 Seconds
Mechanical Shutter
1/8000 to 60 Seconds
Bulb/Time Mode
Bulb Mode (Up to 30 Minutes)
ISO/Gain Sensitivity
Native: 100 to 25,600 (50 to 25,600 Extended)
Video
Native: 100 to 12,800 (50 to 12,800 Extended)
Metering Method
Center-Weighted Average, Highlight Weighted, Multiple, Spot
Exposure Modes
Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation
-5 to +5 EV (1/3 EV Steps)
Metering Range
0 to 18 EV
White Balance
2500 to 10,000K
Presets: AWB, Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
Continuous Shooting
Up to 75 fps at Maximum Resolution for up to 215 Frames (Raw) / 260 Frames (JPEG)
Self-Timer
2/3/10-Second Delay
Still Image Capture
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Image File Format
JPEG, Raw
Video Capture
Internal Recording
ProRes RAW/ProRes RAW HQ
5728 x 3024 at 23.98/24.00/25/29.97/50 fps [1 to 4.2 Gb/s]
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps [1.1 to 4.2 Gb/s]
1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [121 to 454 Mb/s]
H.264/MOV/MPEG-4 AVC 4:2:2 10-Bit
5728 x 3024 at 23.98/24.00/25/29.97 fps [1000 to 1900 Mb/s]
H.264 ALL-Intra/MOV 4:2:2 10-Bit
4096 x 2160 from 1 to 59.94 fps [400 to 800 Mb/s]
3840 x 2160 from 1 to 59.94 fps [400 to 800 Mb/s]
1920 x 1080p from 1 to 240 fps [200 to 800 Mb/s]
1920 x 1080i at 50/59.94 fps [100 Mb/s]
H.264 Long GOP/MOV/MPEG-4 AVC 4:2:2 10-Bit
4096 x 2160 from 1 to 59.94 fps [150 to 200 Mb/s]
3840 x 2160 from 1 to 59.94 fps [150 to 200 Mb/s]
1920 x 1080p from 1 to 240 fps [100 to 200 Mb/s]
1920 x 1080i at 50/59.94 fps [50 Mb/s]
H.265 Long GOP/MOV 4:2:0 10-Bit
5760 x 4320 at 23.98/24.00/25/29.97 fps [200 Mb/s]
4352 x 3264 at 47.95/48.00/50/59.94 fps [300 Mb/s]
5728 x 3024 from 1 to 59.94 fps [200 to 300 Mb/s]
4096 x 2160 [150 to 300 Mb/s]
3840 x 2160 [72 to 300 Mb/s]
1920 x 1080p from 1 to 300 fps [20 to 200 Mb/s]
Video Output
4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps
UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps
1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
Raw 12-Bit via HDMI
5760 x 4320
5744 x 3024
DCI 4K (4096 x 2160)
Fast-/Slow-Motion Support
Yes
Gamma Curve
Panasonic V-Gamut, Panasonic V-Log
Recording Limit
No
IP Streaming
RTMP, RTMPS
1280 x 720 to 1920 x 1080 at 29.97p, 59.94p (4.0 to 16.00 Mb/s)
RTMP, RTMPS, UVC/UAC
3840 x 2160 at 29.97p (4.0 to 16.00 Mb/s)
1280 x 720 to 1920 x 1080 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.00 Mb/s)
RTP, RTSP
1280 x 720 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 50.00 Mb/s)
Built-In Microphone
Stereo
Audio Recording
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio
MP4: 2-Channel 16-Bit 48 kHz AAC Audio
Interface
Media/Memory Card Slot
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II) [U3/V30 or Faster Recommended]
Internal Storage
No
Video I/O
1x HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x 2.5 mm Sub-Mini Remote Input
1x USB-C Data Input/Output (Shared with Power Input)
Wireless
5 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0 Video Output, Audio Output, Control
Mobile App Compatible
Yes: Android & iOS
App Name: Panasonic LUMIX Sync/Lumix Lab
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
GPS
*Via Connected Smartphone
Monitor
Display Type
Free-Angle Tilting 3" Touchscreen LCD
Resolution
1,840,000 Dot
Viewfinder
Type
Electronic (OLED)
Resolution
3,680,000 Dot
Eye Point
21 mm
Coverage
100%
Magnification
Approx. 0.76x
Diopter Adjustment
-4 to +3
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Automatic, Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, Single-Servo AF, Touch AF & Shutter
Autofocus Points
Photo, Video
Contrast Detection: 315
Autofocus Sensitivity
-4 to +18 EV
Flash
Built-In Flash/Light
No
Flash Modes
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction
Maximum Sync Speed
1/250 Second
Flash Compensation
-3 to +3 EV (1/3 EV Steps)
Dedicated Flash System
TTL
External Flash Connection
Shoe Mount
