Key Specs
Lens Mount
L-Mount
Sensor Resolution
Actual: 25.3 Megapixel
Effective: 24.2 Megapixel (6000 x 4000)
Image Sensor
35.6 x 23.8 mm (Full-Frame) CMOS
Image Stabilization
Sensor-Shift, 5-Axis
ISO/Gain Sensitivity
Native: 100 to 51,200 (50 to 204,800 Extended)
Internal Recording
H.264 Long GOP/H.265 Long GOP/MOV 4:2:2/4:2:0
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97 fps [150 Mb/s]
3840 x 2160 at 23.98/24.00/25/29.97 fps [150 Mb/s]
1920 x 1080 at 23.98/24.00/29.97/47.95/48.00/50/59.94/100/120 fps [100 to 150 Mb/s]
H.265 Long GOP/MOV 4:2:0 10-Bit
5952 x 3968 at 23.98/24.00/25/29.97 fps [200 Mb/s]
5888 x 3312 at 23.98/24.00/25/29.97 fps [200 Mb/s]
5952 x 3136 at 23.98/24.00/25/29.97 fps [200 Mb/s]
H.265 Long GOP/MP4/MP4 Lite 4:2:0 8/10-Bit
3840 x 2560 at 25 fps [50 Mb/s]
3840 x 2160 at 23.98/25/29.97 fps [72 to 100 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [20 to 28 Mb/s]
Show More
Video Output
4:2:2 8/10-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080p
1920 x 1080i
Show More
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Video I/O
1x Micro-HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C Data Output (Shared with Power Input)
Wireless
Wi-Fi 5 (802.11ac), Bluetooth 5.0
Display Type
Free-Angle Tilting Touchscreen LCD
Battery
1x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Included)
Imaging
Lens Mount
L-Mount
Sensor Resolution
Actual: 25.3 Megapixel
Effective: 24.2 Megapixel (6000 x 4000)
Image Sensor
35.6 x 23.8 mm (Full-Frame) CMOS
Sensor Crop (35mm Equivalent)
Crop Factor: 1x
*Additional Crop Occurs in Select Video Modes
Image Stabilization
Sensor-Shift, 5-Axis
Built-In ND Filter
No
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
Electronic Shutter
1/8000 to 60 Seconds in Manual Mode
1/16000 to 1/25 Second in Movie Mode
Bulb/Time Mode
Bulb Mode
ISO/Gain Sensitivity
Native: 100 to 51,200 (50 to 204,800 Extended)
Metering Method
Center-Weighted Average, Highlight Weighted, Multiple, Spot
Exposure Modes
Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation
-5 to +5 EV (1/3 EV Steps)
Metering Range
0 to 18 EV
White Balance
2500 to 10,000K
Presets: AWB, Cloudy, Color Temperature, Daylight, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
Continuous Shooting
Up to 30 fps at Maximum Resolution
Interval Recording
Yes
Self-Timer
2/10-Second Delay
Still Image Capture
Aspect Ratio
1:1, 2:1, 3:2, 4:3, 16:9, 65:24
Image File Format
JPEG, Raw
Video Capture
Internal Recording
H.264 Long GOP/H.265 Long GOP/MOV 4:2:2/4:2:0
DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97 fps [150 Mb/s]
3840 x 2160 at 23.98/24.00/25/29.97 fps [150 Mb/s]
1920 x 1080 at 23.98/24.00/29.97/47.95/48.00/50/59.94/100/120 fps [100 to 150 Mb/s]
H.265 Long GOP/MOV 4:2:0 10-Bit
5952 x 3968 at 23.98/24.00/25/29.97 fps [200 Mb/s]
5888 x 3312 at 23.98/24.00/25/29.97 fps [200 Mb/s]
5952 x 3136 at 23.98/24.00/25/29.97 fps [200 Mb/s]
H.265 Long GOP/MP4/MP4 Lite 4:2:0 8/10-Bit
3840 x 2560 at 25 fps [50 Mb/s]
3840 x 2160 at 23.98/25/29.97 fps [72 to 100 Mb/s]
1920 x 1080 at 23.98/25/29.97/50/59.94 fps [20 to 28 Mb/s]
Video Output
4:2:2 8/10-Bit via HDMI
4096 x 2160
3840 x 2160
1920 x 1080p
1920 x 1080i
Fast-/Slow-Motion Support
Yes
Gamma Curve
HDR-HLG, Panasonic V-Log
Recording Limit
15-Minute Maximum in 4K
IP Streaming
No
Built-In Microphone
Stereo
Audio Recording
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio
MP4: 2-Channel 16-Bit 48 kHz AAC Audio
Interface
Media/Memory Card Slot
Single Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Video I/O
1x Micro-HDMI Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Power I/O
1x USB-C Input
Other I/O
1x USB-C Data Output (Shared with Power Input)
Wireless
Wi-Fi 5 (802.11ac), Bluetooth 5.0
Mobile App Compatible
Yes: Android & iOS
App Name: LUMIX Lab / LUMIX Sync
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)
GPS
*Via Connected Smartphone
Monitor
Display Size
3"
Resolution
1,840,000 Dot
Display Type
Free-Angle Tilting Touchscreen LCD
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points
Contrast Detection, Phase Detection: 779
Flash
Built-In Flash/Light
No
External Flash Connection
No
General
Battery
1x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Included)
Shoe Mount
1x Cold Shoe
Tripod Mounting Thread
1x 1/4"-20 Female (Bottom)
Operating Conditions
32 to 104°F / 0 to 40°C at 10 to 80% Humidity
Dimensions (W x H x D)
4.96 x 2.91 x 1.84" / 12.6 x 7.39 x 4.67 cm
Weight
0.9 lb / 403 g (Body Only)
1.1 lb / 486 g (With Battery, Recording Media)
