Key Specs
Image Sensor
1"-Type
Effective Sensor Resolution
14 Megapixel
Image Stabilization
Optical in Integrated Lens
Digital
ISO/Gain Sensitivity
Native: 250 to 16,000
Gain: -3 to 36 dB
Max Recording Modes
XAVC HS-L
UHD 4K up to 23.98/50/59.94/100/120 fps
XAVC S-I
Up to UHD 4K at 23.98/25/29.97/50/59.94 fps
XAVC S-L
Up to UHD 4K at 23.98/25/29.97/50/59.94/100/120 fps
Show More
Max Video Output
Up to UHD 4K at 23.98/25/29.97/50/59.94/100/120 fps
Media/Memory Card Slot
Dual Slot: CFexpress Type A / SDXC (UHS-II)
Mobile App Compatible
Yes: Android & iOS
Battery
Sony BP-U Series
Imaging
Image Sensor
13.2 x 8.8 mm (1"-Type) CMOS
Sensor Resolution
Effective: 14 Megapixel
Actual: 20.9 Megapixel
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
2 to 7 Stop Electronic ND Filter
Capture Type
Video Only
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/8000 to 64 Seconds
Shutter Angle
5.6 to 360°
ISO/Gain Sensitivity
Native: 250 to 16,000
Gain: -3 to 36 dB
Signal-to-Noise Ratio
Not Specified by Manufacturer
Minimum Illumination
1.2 Lux
White Balance
Range: 2000 to 15,000K
Presets: ATW, Auto
Lens
Focal Length
7.71 to 154.21mm (35mm Equivalent: 24 to 480mm)
Zoom
20x Optical
Maximum Aperture
f/2.8 to 4.5
Minimum Aperture
f/11
Minimum Focus Distance
0.4" / 1 cm
Filter Size
72 mm
Control Rings
Focus
Zoom
Focus
Focus Mode
Automatic, Manual Focus
Autofocus Points
Phase Detection: 475
Video Capture
Internal Recording
XAVC HS-L
3840 x 2160 up to 23.98/50/59.94/100/120 fps (30 to 280 Mb/s)
XAVC S-I
3840 x 2160 at 23.98/25/29.97/50/59.94 fps (240 to 600 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
XAVC S-L
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps (100 to 280 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
Video Output
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080i at 25/29.97/50/59.94/100/120 fps
Broadcast Output
NTSC
PAL
Fast-/Slow-Motion Support
Yes
Interval Recording Modes
No
Gamma Curve
HDR-HLG, Rec709, S Cinetone, Sony S-Log 3
Built-In Microphone
Stereo
Audio Recording
4-Channel, 24-Bit at 48 kHz via LPCM Audio
IP Streaming
H.264, H.265, RTMP, RTMPS, SRT
3840 x 2160
1920 x 1080
1280 x 720
Interface
Media/Memory Card Slot
Dual Slot: CFexpress Type A / SDXC (UHS-II)
Internal Storage
No
Video I/O
1x HDMI Output
Audio I/O
2x XLR 3-Pin Input
1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Input
Power I/O
1x Barrel (19.5VDC)
Other I/O
1x 2.5 mm Sub-Mini (Remote) Control
1x RJ45 (LAN) Control
1x USB-C (USB 3.2 / 3.1 Gen 1)
Wireless
Wi-Fi 5 (802.11ac)
Mobile App Compatible
Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD
Resolution
1280 x 720 (2,359,296 Dot)
Viewfinder
Type
Electronic
Resolution
1024 x 768
Environmental
Operating Conditions
32 to 104°F / 0 to 40°C
Storage Conditions
-4 to 140°F / -20 to 60°C
General
Shoe Mount
1x Intelligent Hot Shoe
Tripod Mount
1/4"-20 Female
3/8"-16 Female
Tripod Mount
1/4"-20 Female
3/8"-16 Female
Accessory Mounting Thread
2x 1/4"-20
Dimensions (W x H x D)
6.9 x 7.9 x 14.6" / 175.6 x 201.3 x 371.6 mm
Weight
4 lb / 1.93 kg (Body Only)
