Product TypeDigital camera - SLR with Live View mode, movie recording
Sensor Resolution22.3 Megapixel
Optical Sensor TypeCMOS
Total Pixels23,400,000 pixels
Effective Sensor Resolution22,300,000 pixels
Optical Sensor Size24 x 36mm
Field of View Crop Factor1.0
Sensor Dust ReductionYes
Sensor FeaturesEOS Integrated Cleaning System
Image ProcessorDual DIGIC 5+
Auto FocusTTL phase detection
Auto Focus Points (Zones) Qty61
AE/AF ControlPredictive AI Servo AF
Face DetectionLive Face detection AF mode
Digital Video FormatH.264, MOV
Image Recording FormatJPEG, RAW, RAW + JPEG
Max Video Resolution1920 x 1080
AV InterfacesComposite video/audio, HDMI
Light SensitivityISO 50, ISO 102400, ISO auto (100-12800), ISO 51200, ISO 25600, ISO 100-12800, ISO 16000, ISO 20000
Exposure MeteringEvaluative, center-weighted, partial (7.2%), spot (1.5%)
Exposure Metering Zones63
Exposure ModesProgram, bulb, automatic, manual, aperture-priority, shutter-priority, E-TTL II program flash
Special EffectsNeutral, Faithful, Monochrome, Landscape, Portrait
White BalanceCustom, automatic, presets
White Balance PresetsCloudy, tungsten light, flash, daylight, shade, fluorescent light (daylight white)
Max Shutter Speed1/8000 sec
Min Shutter Speed30 sec
Exposure Compensation±5 EV range, in 1/2 or 1/3 EV steps
Auto Exposure Bracketing3 steps in 1/2 or 1/3 EV steps
White Balance BracketingYes
X-sync Speed1/200 sec
Exposure RangeEV 1-20 ( ISO 100 )
Lens System MountingCanon EF
Continuous Shooting Speed3 frames per second, 6 frames per second
Self Timer Delay10 sec, 2 sec
Flash TerminalHot shoe, PC terminal
Status LCD Display IlluminationYes
Additional FeaturesDirect print, RGB primary color filter, auto power save, digital noise reduction, DPOF support, display brightness control, depth-of-field preview button, digital image rotation, camera orientation detection, PictBridge support, histogram display, AE lock, AF lock, FE lock, cropping an image, highlight point display, 1080p Full HD movie recording, Dust Delete Data system, face detection, Auto Lighting Optimizer, Exif Print support, in-camera RAW processing, automatic display brightness adjustment, peripheral illumination correction, Chromatic Aberration Compensation (CAC), Constant AF Live View, HDR image enhancement technology, Scene Intelligent Auto technology, Predictive Focus Control, Lens Distortion Compensation (LDC), Dual Axis Electronic Level, Backup recording
Viewfinder TypeOptical - fixed eye-level pentaprism
Field Coverage100%
Magnification0.71x
Dioptric Correction Range-3 to +1
Viewfinder FramesAutofocus frame
Viewfinder InformationShutter speed, exposure compensation, AE lock, AF-in-focus, flash charge completion, red-eye reduction , aperture, battery status, high-speed sync indicator, flash compensation on/off, highlight tone priority, ISO sensitivity, memory card status, FE lock, AF status, AF point, grid, electronic level, maximum burst
Type3.2" LCD display
Resolution1,040,000 pixels
Display FeaturesBuilt-in
Connector Type1 x Hi-Speed USB 1 x composite video/audio output 1 x HDMI output 1 x microphone
Memory Card SlotCompactFlash Card, SD card
SoftwareDrivers & Utilities, Canon PhotoStitch, Canon Remote Capture, Canon Digital Photo Professional, Canon ImageBrowser EX
Operating System SupportMS Windows XP SP2 or later, MS Windows 7, MS Windows Vista SP1, Apple Mac OS X 10.6 - 10.7
Peripheral DevicesUSB port, CD-ROM drive
Memory Card SlotCompactFlash Card, SD card
Supported Memory CardsCompactFlash, SD Memory Card, SDXC Memory Card, SDHC Memory Card
Image StorageRAW 5760 x 3840 RAW 3960 x 2640 RAW 2880 x 1920 JPEG 5760 x 3840 JPEG 3840 x 2560 JPEG 2880 x 1920 JPEG 1920 x 1280 JPEG 720 x 480
Video CaptureH.264 - 1920 x 1080 - 30 fps H.264 - 1920 x 1080 - 25 fps H.264 - 1920 x 1080 - 24 fps H.264 - 1280 x 720 - 60 fps H.264 - 1280 x 720 - 50 fps H.264 - 640 x 480 - 30 fps H.264 - 640 x 480 - 25 fps
Width6 in
Depth3 in
Height4.6 in
Weight1.9 lbs
Min Operating Temperature32 °F
Max Operating Temperature104 °F
