Canon R5 C Specs
Imaging
Lens Mount Canon RF
Lens Communication Yes, with Autofocus Support
Sensor Resolution Actual: 47.1 Megapixel
Effective: 45 Megapixel (8192 x 5464)
Sensor Type 36 x 24 mm (Full-Frame) CMOS
Crop Factor 1.6x
Pixel Pitch 5.5 µm
Image Stabilization Digital
Built-In ND Filter None
Internal Filter Holder No
Capture Type Stills & Video
Exposure Control
Shutter Type Electronic Shutter, Mechanical Focal Plane Shutter
Shutter Speed Mechanical Shutter
1/8000 to 30 Seconds
Electronic Front Curtain Shutter
1/8000 to 30 Seconds
Electronic Shutter
1/8000 to 0.5 Seconds
Bulb/Time Mode Bulb Mode
ISO Sensitivity Photo
100 to 51,200 in Manual Mode (Extended: 50 to 102,400)
100 to 12,800 in Auto Mode (Extended: 100 to 51,200)
Video
100 to 51,200 (Extended: 50 to 102,400)
Metering Method Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Metering Range -3 to 20 EV
White Balance 0 to 0K
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Tungsten
Continuous Shooting Mechanical Shutter
Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG)
Electronic Shutter
Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG)
Interval Recording Yes
Self-Timer 2/10-Second Delay
Internal Video Capture
Raw Recording Raw, Cinema RAW Light
8192 x 5464 at 23.98/24.00/25/29.97/50/59.94 fps [1030 to 2570 Mb/s]
5952 x 3140 at 23.98/24.00/29.97/50/59.94 fps [544 to 1360 Mb/s]
2976 x 1570 at 23.98/24.00/25/29.97/50/59.94 fps [138 to 344 Mb/s]
Recording Modes Raw 12-Bit
DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [2600 Mb/s]
AVC-Intra/AVC-LongG/XF-AVC 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/59.94p/100p/119.88p [160 to 810 Mb/s]
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/100p/119.88p [160 to 810 Mb/s]
Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [50 to 310 Mb/s]
HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s]
AVC-LongG/MP4 4:2:2 10-Bit
DCI 8K (8192 x 4320) at 23.98p/24.00p/25p/29.97p [400 to 540 Mb/s]
UHD 8K (7680 x 4320) at 23.98p/25p/29.97p [400 to 540 Mb/s]
DCI 4K (4096 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p/100p/119.88p [100 to 225 Mb/s]
UHD 4K (3840 x 2160) at 23.98p/25p/29.97p/50p/59.94p/119.88p [100 to 225 Mb/s]
DCI 2K (2048 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p [35 to 50 Mb/s]
Full HD (1920 x 1080) at 23.98p/25p/29.97p/50p/59.94p [35 to 50 Mb/s]
HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s]
AVC-LongG/MP4 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.98PsF/24.00p/25p/29.97p/50p/59.94p/119.88p [100 to 225 Mb/s]
UHD 4K (3840 x 2160) at 23.98p/24.00p/25p/29.97p/50p/59.94p [100 to 225 Mb/s]
DCI 2K (2048 x 1080) at 23.98p/24.00p/25p/29.97p/50p/59.94p [35 to 50 Mb/s]
Full HD (1920 x 1080) at 23.98p/24.00p/29.97p/50p/59.94p [35 to 50 Mb/s]
HD (1280 x 720) at 50p/59.94p [8 to 12 Mb/s]
Sensor Crop Modes Super35 / APS-C
5952 x 3184
4096 x 2160
3840 x 2160
Super16
2976 x 1570
Gamma Curve Canon Log 3, HDR-HLG, HDR-PQ, Rec709, Rec2020
Recording Limit Unlimited
Broadcast Output NTSC/PAL
External Video Capture
External Recording Modes 4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) up to 59.94p
UHD 4K (3840 x 2160) up to 59.94p
IP Streaming None
Still Image Capture
Image Sizes 3:2 JPEG / Raw
8192 x 5464
5088 x 3392
3:2 JPEG / Raw
8192 x 5464
5808 x 3872
4176 x 2784
2400 x 1600
4:3 JPEG / Raw
7280 x 5464
5152 x 3872
3715 x 2784
2112 x 1600
16:9 JPEG / Raw
8192 x 4608
5808 x 3264
4176 x 2344
2400 x 1344
1:1 JPEG / Raw
5456 x 5456
3872 x 3872
2784 x 2784
1600 x 1600
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Image File Format C-RAW, HEIF, JPEG, Raw
Bit Depth 14-Bit
Interface
Media/Memory Card Slot Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II)
Video I/O 1 x Micro-HDMI Output
Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O 1 x USB Type-C (9 VDC at 3 A) Input
Other I/O 1 x USB Type-C (USB 3.2 / 3.1 Gen 2) (Shared with Power Input)
Wireless Bluetooth Control
2.4 / 5 GHz Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Wi-Fi Video Output, Control
Global Positioning (GPS, GLONASS, etc.) None
Monitor
Size 3.2"
Resolution 2,100,000 Dot
Display Type Free-Angle Tilting Touchscreen LCD
Viewfinder
Type Built-In Electronic (OLED)
Size 0.5"
Resolution 5,790,000 Dot
Eye Point 23 mm
Coverage 100%
Magnification Approx. 0.76x
Diopter Adjustment -4 to +2
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points Phase Detection: 1053
Autofocus Sensitivity -6 to +20 EV
Built-In Flash No
Maximum Sync Speed 1/250 Second
Flash Compensation -3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System eTTL
External Flash Connection Hot Shoe
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 0 to 85%
