Key Specs
Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Internal Recording
H.264/MP4 4:2:0 8-Bit
3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
H.265/MP4 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s]
H.265/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s]
MXF/XF-AVC 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s]
1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
Show More
Video Output
SDI/BNC
UHD 4K (3840 x 2160) up to 59.94 fps
Media/Memory Card Slot
Slot 1: SD/SDHC/SDXC
Slot 2: SD/SDHC/SDXC
Video I/O
1x HDMI 2.0 Output
1x BNC (12G-SDI) Output
Battery Type
Canon BP-A Series
Imaging
Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/2000 to 1/4 Second
Shutter Angle
11 to 360°
Sensitivity
f/12 at 2000 lux
Minimum Illumination
1.5 Lux at 1/30 Shutter Speed
White Balance
Range: 2000 to 15,000K
Lens
Focal Length
8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio
15x
Max Digital Zoom
30x ( in 1080p)
Maximum Aperture
f/2.8
Minimum Aperture
f/4.5
Minimum Focus Distance
2' / 60 cm
Filter Size
58 mm
Control Rings
Focus
Zoom
Iris
Focus Control
Autofocus
Manual Focus
Video Capture
Internal Recording
H.264/MP4 4:2:0 8-Bit
3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
H.265/MP4 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s]
H.265/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s]
MXF/XF-AVC 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s]
1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
Video Output
SDI/BNC
UHD 4K (3840 x 2160) up to 59.94 fps
Fast-/Slow-Motion Support
Yes
Gamma Curve
Canon Log 3, HDR-HLG
Built-In Microphone
Stereo
Audio Recording
2-Channel 16-Bit 48 kHz AAC Audio
4-Channel 24-Bit 48 kHz LPCM Audio
IP Streaming
MPEG2
1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.0 Mb/s)
1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s)
Interface
Media/Memory Card Slot
Slot 1: SD/SDHC/SDXC
Slot 2: SD/SDHC/SDXC
Video I/O
1x HDMI 2.0 Output
1x BNC (12G-SDI) Output
Audio I/O
2x XLR 3-Pin Input
1x 1/8" / 3.5 mm TRS Stereo Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x Barrel (24VDC) Input
Other I/O
1x USB-A Output
1x USB-C
1x BNC (Genlock, Sync) Input/Output
1x BNC (Timecode) Input/Output
1x 2.5 mm Sub-Mini Control
1x D-Sub 8-Pin Control
1x RJ45 (LAN) Input/Output
Wireless
2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD
Resolution
Primary Monitor: 2,760,000 Dot
Viewfinder
Type
Removable Electronic (OLED)
Resolution
1,770,000 Dot
Focus
Focus Mode
Automatic, Manual Focus
Power
Battery Type
Canon BP-A Series
Power Consumption
21.5 W
Environmental
Operating Conditions
32 to 104°F / 0 to 40°C up to 85% Humidity
General
Shoe Mount
1x Intelligent Hot Shoe
1x Cold Shoe
Tripod Mounting Thread
1/4"-20 Female
3/8"-16 Female
Built-In Video Light
Infrared Only
Dimensions (W x H x D)
15.2 x 8.6 x 8.3" / 385 x 219 x 210 mm (With Protrusions)
13.1 x 6.8 x 6.6" / 333 x 173 x 168 mm (Without Protrusions)
Weight
4.4 lb / 2010 g (Body Only)
