Lens Mount
Camera Format DX / (1.5x Crop Factor)
Pixels Actual: 24.78 Megapixel
Effective: 24.2 Megapixel
Max Resolution 24 MP: 6000 x 4000
Aspect Ratio 3:2
Sensor Type / Size CMOS, 23.5 x 15.6 mm
File Formats Still Images: JPEG, RAW
Movies: MOV, MPEG-4 AVC/H.264
Audio: Linear PCM (Stereo)
Bit Depth 14-bit
Dust Reduction System Yes
Memory Card Type SD
SDHC
SDXC
Focus Control
Focus Type Auto & Manual
Focus Mode Automatic (A), Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S)
Autofocus Points Phase Detection: 39, 9 cross-type
Viewfinder/Display
Viewfinder Type Pentamirror
Viewfinder Eye Point 17.00 mm
Viewfinder Coverage 95%
Viewfinder Magnification Approx. 0.82x
Diopter Adjustment - 1.7 to +0.5 m
Display Screen 3.2" Rear Touchscreen Swivel LCD (1,037,000)
Screen Coverage 100%
Diagonal Angle of View 170.0°
Exposure Control
ISO Sensitivity Auto, 100-25600
Shutter 30 - 1/4000 second, Bulb Mode
Remote Control WR-1, WR-10, MC-DC2 (Optional)
Metering Method Center-weighted average metering, Matrix, Spot metering
Exposure Modes Modes: Aperture Priority, Manual, Program, Scene Modes, Shutter Priority
Metering Range: EV 0.0 - EV 20.0
Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV steps)
Continuous Shooting Up to 5 fps at 24.2 MP
Up to 4 fps at 24.2 MP
Up to 3 fps at 24.2 MP
White Balance Modes Auto, Cloudy, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade
Flash
Flash Modes Auto
Auto/Red-eye Reduction
Fill-in
Rear Curtain Sync/Red-eye Reduction
Rear Curtain/Slow Sync
Red-eye Reduction
Slow Sync
Slow Sync/Red-eye Reduction
Built-in Flash Yes
Guide No. 39.37' (12 m) ISO100
Max Sync Speed 1 / 200 seconds
Flash Compensation -3 EV to +1 EV (in 1/3 or 1/2 EV steps)
Dedicated Flash System iTTL
External Flash Connection Hot Shoe
AV Recording
Video Recording Yes, NTSC/PAL
Video Format High Definition
MOV
1920 x 1080p / 59.94 fps / 50 fps / 29.97 fps
/ 25 fps / 23.98 fps
High Definition
MOV
1280 x 720p / 59.94 fps / 50 fps
Aspect Ratio 16:9
ISO Sensitivity 100 - 25600
Focus Auto
Manual
Continuous Auto
Video Clip Length 1920 x 1080
29 min. 59 seconds
Audio Recording Built-in Mic: With Video, Stereo
Optional External Mic: With Video, Stereo
Performance
Self Timer 20 seconds, 10 seconds, 5 seconds, 2 seconds
Interval Recording Yes
Connectivity HDMI C (Mini), Micro-USB, USB 2.0
Wi-Fi Capable Yes
Operating/Storage Temperature Operating
32 to 104°F (0 to 40°C)
Humidity: 0 - 85%
Physical
Dimensions (WxHxD) 4.9 x 3.8 x 2.8" / 124.0 x 97.0 x 70.0 mm
Weight 1.02 lb / 465 g
Kit Lens
Focal Length
Comparable 35mm Focal Length: 27 - 82.5 mm
Aperture Maximum: f/3.5 - 5.6
Minimum: f/22 - 38
Angle of View 76° - 28° 50'
Minimum Focus Distance 9.84" (25 cm)
Magnification 0.38x
Elements/Groups 12/9
Diaphragm Blades 7, Rounded
Autofocus Yes
Image Stabilization Yes
Filter Thread Front: 55 mm
Dimensions (DxL) Approx. 2.54 x 2.46" (64.5 x 62.5 mm)
Weight 7.23 oz (205 g)
Kit Lens
Focal Length 70-300mm
Comparable 35mm Focal Length: 105-450 mm
Aperture Maximum: f/4.5 - 6.3
Minimum: f/32
Viewing Angle 22° 50' - 5° 20'
Minimum Focus Distance 3.61' (1.1 m)
Magnification 0.22x
Elements/Groups 14/10
Diaphragm Blades 7, Rounded
Autofocus Yes
Image Stabilization No
Filter Thread Front: 58 mm
Dimensions (DxL) Approx. 2.83 x 4.92" (72 x 125 mm)
Weight 14.11 oz (400 g)
Packaging Info
Package Weight 4.0 lb
Box Dimensions (LxWxH) 12.5 x 8.1 x 5.4"
