Imaging
Lens Mount Micro Four Thirds
Camera Format Micro Four Thirds (2x Crop Factor)
Pixels Actual: 17.2 Megapixel
Effective: 16.1 Megapixel
Max Resolution 4608 x 3456
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Sensor Type / Size MOS, 17.3 x 13 mm
File Formats Still Images: JPEG, MPO, RAW
Movies: AVI, MOV, MPEG-4 AVC/H.264
Audio: Linear PCM (Stereo)
Bit Depth 12-bit
Dust Reduction System Yes
Memory Card Type SDHC
SDXC
Image Stabilization Sensor-Shift, 5-Way
AV Recording
Video Recording Yes, NTSC/PAL
Video Format 1920 x 1080p at 23.98, 25, 29.97 fps (77 Mbps MOV)
1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps (52 Mbps MOV)
1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps (30 Mbps MOV)
1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps (18 Mbps MOV)
1280 x 720p at 23.98, 25, 29.97, 50, 59.94 fps (MOV)
1280 x 720p at 30 fps (AVI)
640 x 480p at 120 fps (AVI)
640 x 480p at 30 fps (AVI)
Aspect Ratio 4:3, 16:9
Video Clip Length Up to 29 Min
Audio Recording Built-in Mic: With Video, Stereo
Focus Control
Focus Type Auto & Manual
Focus Mode Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S)
Autofocus Points Contrast Detection: 81
Viewfinder/Display
Viewfinder Type Electronic
Viewfinder Pixel Count 2,360,000
Viewfinder Eye Point 19.2 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 1.08x
Diopter Adjustment -4 to +2 m
Display Screen 3" Rear Touchscreen Tilting LCD (1,040,000)
Exposure Control
ISO Sensitivity Auto, 200-25600 (Extended Mode: Auto, 100-25600)
Shutter Type: Electronic & Mechanical
Speed: 60 - 1/4000 second
Type: Electronic & Mechanical
Speed: .5 - 1 minute in Bulb Mode
Type: Electronic
Speed: 60 - 1/16000 second
Remote Control RM-UC1 (Optional)
Metering Method Center-weighted average metering, Multi-zone metering, Spot metering, Highlight Weighted
Exposure Modes Modes: Aperture Priority, Art Filter, Bulb, Intelligent Auto, Manual, Program Shift, Programmed Auto, Scene Selection, Shutter Priority, Time, Underwater
Metering Range: EV -2.0 - EV 20.0
Compensation: -5 EV to +5 EV (in 1/3, 1/2 or 1 EV steps)
White Balance Modes Auto, Custom
Continuous Shooting Up to 8.5 fps at 16.1 MP for up to 36 frames
Up to 4 fps at 16.1 MP for up to frames
Flash
Flash Modes Auto
Fill-in
Manual
Off
Red-eye Reduction
Second-curtain Sync
Slow Sync
Slow Sync/Red-eye Reduction
Built-in Flash Yes
Guide No. 19.03' (5.8 m) ISO100
Max Sync Speed 1 / 250 seconds
Flash Compensation -3 EV to +3 EV (in 1/3, 1/2 or 1 EV steps)
Dedicated Flash System TTL Remote Firing Groups: 4 Channels: 4
External Flash Connection Hot Shoe
Performance
Self Timer 12 seconds, 2 seconds
Custom: 1-30 seconds at 0.5, 1.0, 2.0, 3.0 second intervals
Number of Shots: 1-10
Interval Recording Yes
Connectivity HDMI D (Micro), USB 2.0
Wi-Fi Capable Yes
Power
Battery 1x BLS-50 Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1175 mAh
Operating/Storage Temperature Operating
32 to 104°F (0 to 40°C)
Humidity: 30 - 90%
Physical
Dimensions (WxHxD) 4.7 x 3.3 x 1.8" / 119.5 x 83.1 x 46.7 mm
Weight 13.76 oz / 390 g with battery and memory card
Packaging Info
Package Weight 2.6 lb
Box Dimensions (LxWxH) 9.4 x 9.1 x 3.9"
