Panasonic DC-GH5 II Specs
Imaging
Lens Mount Micro Four Thirds
Sensor Type 17.3 x 13 mm (4/3") MOS
Sensor Resolution Actual: 21.77 Megapixel
Effective: 20.33 Megapixel
Crop Factor 2x
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Image File Format JPEG, Raw
Bit Depth 14-Bit
Image Stabilization Sensor-Shift, 5-Axis
Exposure Control
ISO Sensitivity Auto, 200 to 25600 (Extended: 100 to 25600)
Shutter Speed Electronic Shutter
1/16000 to 60 Second
1 to 60 Seconds in Bulb Mode
Electronic Front Curtain Shutter
1/2000 to 60 Seconds
1 to 30 Minutes in Bulb Mode
Metering Method Center-Weighted Average, Highlight Weighted, Multiple, Spot
Exposure Modes Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation -5 to +5 EV (1/3 EV Steps)
Metering Range 0 to 18 EV
White Balance Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
Continuous Shooting Up to 12 fps at 20.3 MP
Up to 30 fps at 18 MP
Up to 60 fps at 8 MP
Interval Recording Yes
Self-Timer 2/10-Second Delay
Video
Recording Modes H.265/MOV 4:2:0 10-Bit
6K Anamorphic (4992 x 3774) at 23.976p/24.00p/25p/29.97p [200 Mb/s]
4K Anamorphic (3328 x 2496) at 50p [200 Mb/s]
DCI 4K (4096 x 2160) at 50p/59.94p [200 Mb/s]
UHD 4K (3840 x 2160) at 50p/59.94p [200 Mb/s]
H.264/MOV 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p [150 to 400 Mb/s]
DCI 4K (4096 x 2160) at 50p/59.94p [200 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p [150 to 400 Mb/s]
4K Anamorphic (3328 x 2496) at 23.976p/24.00p/25p/29.97p [150 to 400 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 200 Mb/s]
H.264/MOV 4:2:0 8-Bit
4K Anamorphic (3328 x 2496) at 23.976p/24.00p/29.97p/50p/59.94p [100 to 150 Mb/s]
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p [100 to 150 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 150 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 Mb/s]
H.265/MP4 4:2:0 10-Bit
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p [72 to 100 Mb/s]
H.264/MP4 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p [100 Mb/s]
Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p [20 to 28 Mb/s]
External Recording Modes 4:2:2 10-Bit
Recording Limit Unlimited
Video Encoding NTSC/PAL
ISO Sensitivity Auto: 200 to 12800 (Extended: 100 to 12800)
Audio Recording Built-In Microphone (Stereo)
External Microphone Input (Stereo)
Audio File Format AAC, Linear PCM
Live Streaming Yes
Webcam Functionality Yes
Focus
Focus Type Auto and Manual Focus
Focus Mode Automatic (A), Continuous-Servo AF (C), Flexible (AFF), Manual Focus (M), Single-Servo AF (S)
Autofocus Points Contrast Detection: 225
Autofocus Sensitivity -4 to +18 EV
Viewfinder
Viewfinder Type Electronic (OLED)
Viewfinder Resolution 3,680,000 Dot
Viewfinder Eye Point 21 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 76x
Diopter Adjustment -4 to +3
Monitor
Size 3"
Resolution 1,840,000 Dot
Display Type Free-Angle Tilting Touchscreen LCD
Flash
Built-In Flash No
Flash Modes Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction
Maximum Sync Speed 1/250 Second
Flash Compensation -3 to +3 EV (1/3 EV Steps)
Dedicated Flash System TTL
External Flash Connection Hot Shoe, PC Terminal
Interface
Media/Memory Card Slot Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Connectivity USB Type-C (USB 3.1), HDMI A (Full Size), 2.5mm Sub-Mini, 3.5mm Headphone, 3.5mm Microphone
Wireless Wi-Fi
Bluetooth
GPS No
Environmental
Operating Temperature 14 to 104°F / -10 to 40°C
Operating Humidity 10 to 80%
