Product TypeLED-backlit LCD TV
Power Consumption Operational257 Watt
Diagonal Size55"
Viewable Size54.6 in
SeriesBRAVIA XBR X800B Series
TV Tuner1x analog/digital combo
Video InterfaceComponent, composite, HDMI
HDMI Ports Qty4 port(s)
PC InterfaceMobile High-Definition Link (MHL)
HDCP CompatibleYes
Timer FunctionsSleep, wake
DimensionsWithout stand
Width48.5 in
Depth2.6 in
Height29.2 in
Weight51.8 lbs
Enclosure ColorSilver
Resolution3840 x 2160
Display Format4K UHDTV (2160p)
Image Aspect Ratio16:9
Motion Enhancement TechnologyMotionflow XR 240 technology
24p Technology24p True Cinema
LCD Backlight TechnologyLED backlight - frame dimming
Widescreen ModesConventional 4:3, Auto Wide, Full, Wide Zoom, Zoom, Normal, Panorama, Caption
Viewing Angle178 degrees
Viewing Angle (Vertical)178 degrees
Display Menu LanguageEnglish, French, Spanish
Comb Filter3D digital
Commercial FeaturesHotel mode, Variable Audio Output, Demo Mode
Additional FeaturesClock, Advanced Contrast Enhancer circuit (ACE), LightSensor Technology, Live Colour, channel labeling, game mode, Deep Color, picture frame mode, BRAVIA Sync Function, MPEG Noise Reduction, InstaPort, PhotoTV HD, backlight off mode, Wi-Fi CERTIFIED, infobanner, skin naturalizer, Opera browser, picture adjustments lock, Frame Blinking, Start Up Sony Logo Display, Wi-Fi Direct, Face Area Detection, 4K X-Reality PRO Engine, Miracast support, Screen Mirroring, Tv SideView, Opera Apps, Dynamic Backlight Control, One-Touch Mirroring, Seamless Streaming, Intelligent Picture Optimizer, Scene Optimized Energy Saving, Illumination LED, Channel Block, Auto Photo Mode, Clear Mode, One-Flick Entertainment, TV Tweet, 4K Upscaling, Photo Share, Social viewing
StandIncluded
Stand DesignTabletop
Stand ColorSilver
Flat Panel Mount Interface300 x 300 mm
Analog TV TunerNTSC
Multi-channel PreviewPicture-and-picture (PAP)
Reception SystemNTSC-M
Stereo Reception SystemMTS
Channel CoverageVHF:2-13, UHF:14-69, Cable:1-135
Secondary Audio Program (SAP)Yes
Digital TV TunerATSC, QAM
Analog Video Input SignalsNTSC
Input Video Formats1080/24p, 1080/60i, 480/60p, 720/60p, 1080/60p, 1080/30p, 480/60i, 2160/24p, 2160/25p, 2160/30p, 720/24p, 720/30p, 2160/60p
Supported Computer Resolutions1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 768 (WXGA), 1280 x 1024 (SXGA), 1360 x 768, 1920 x 1080
Parental Channel LockYes
Closed Caption CapabilityYes
Supported Video FormatsMPEG-1, MPEG-2, MPEG-4, Motion-JPEG, Xvid, WMV, AVI, MKV, MOV, AVCHD, TS, 3GPP, PS, WebM
Supported Audio FormatsMP3, WMA, WAV, LPCM
Supported Pictures FormatsJPG, RAW, MPO
USB PortYes , 3 port(s)
TypeRemote control
Remote Control ModelSony RM-YD103
FeaturesScene Select
Digital Audio FormatDolby Digital output, Dolby Digital Plus output, Dolby Pulse output
Surround ModeYes
Sound EffectsS-FORCE Front Surround Sound
Audio ControlsSound mode
Speaker System2 speakers
Output Power / Total20 Watt
Additional FeaturesDown-firing Speaker, S-Master Digital Amplifier, Audio Return Channel (ARC), auto mute, Sound Booster, Alternate Audio, Clear Phase Speaker, Advanced Auto Volume, Signal-to-Sound Architecture
Speaker(s)2 x main channel speaker - built-in - 10 Watt
Driver DetailsMain channel speaker : 2 x full-range driver - 30 x 80mm
FunctionalityDigital audio playback, digital photo playback, digital video playback, WEB browsing, Skype client, Internet video playback
ConnectivityWi-Fi, LAN
LAN ProtocolEthernet
Wi-Fi Protocol802.11b, 802.11g, 802.11n, 802.11a
Internet Streaming ServicesSony Entertainment Network
DLNAYes
Connector Type1 x network ( RJ-45 ) - rear 2 x audio line-in - rear 1 x composite video / component video input ( RCA phono x 3 ) - rear 1 x composite video input ( RCA phono ) - rear 1 x audio line-out / headphones / subwoofer ( mini-phone stereo 3.5 mm ) - side 3 x USB 2.0 ( 4 pin USB Type A ) - side 1 x SPDIF output - rear 4 x HDMI ( 19 pin HDMI Type A ) - side
Included AccessoriesIR Blaster
Compliant StandardsUL, cUL
Power DevicePower supply
Nominal VoltageAC 120/230 V ( 50/60 Hz )
Power Consumption Stand by0.2 Watt
Service & Support1 year warranty
Service & Support DetailsLimited warranty - 1 year
Dimensions & Weight DetailsPanel without stand - 48.5 in x 2.6 in x 29.2 in x 51.8 lbs Panel with stand - 48.5 in x 11.2 in x 30.9 in x 53.1 lbs
Width (Shipping)52.3 in
Depth (Shipping)7.8 in
Height (Shipping)32.6 in
Weight (Shipping)70.5 lbs
